TGF SUN TUNNEL SKYLIGHT FEATURES
Optically Engineered
Designed to capture light through a dome on the roof and send it through a reflective tube.
Complete Kit
Includes dome, flashing, ceiling ring, diffuser, & 8 feet of flexible tubing.
Flexible Tube
Flexible tube can be cut to fit and is not recommended for long tunnel runs.
Specifications
Details
| Dome/Lens Type | Acrylic or Polycarbonate | Installation Type | Self-flashed |
| Tube Type | Flexible | Required roof pitch | 14-60 degrees |
| Tube Diameter | 22 in | Exterior Finish | Gray |
| Tube Length Included | 8 ft | Flashing Material | Metal |
| Max. Tube Length | 12 ft | Lighting Area | 325 sq ft |
NFRC Ratings
| Model | Standard | With Energy Kit |
| U-Factor | 0.42 | 0.26 |
| Solar Heat Gain SHGC | 0.32 | 0.26 |
| Visible Transmittance VT | 0.28 | 0.25 |
| ENERGY STAR 7.0 | Northern | Northern |
| Colorado's Water & Efficiency Standards | Compliant | Compliant |
Warranty / Certifications
| Product Warranty | 10-year limited |
| Florida Product Approval | FL6393.13-14 |
| High Velocity Hurricane Zone HVHZ | No |
| IAPMO | UES #0199 |
| WDMA Hallmark Certified | Yes |
| Cali Prop 65 Warning | Yes |
California residents: This product can expose you to Nickel which is known by the State of California to cause cancer, birth defects or other reproductive harm. Click to learn more
Colorado residents: Skylights with U-Factor > 0.50 are intended solely for non-residential applications. Click to learn more
